We present a methodology to assess the damage on MOSFETs after non-conducting off-state induced hard breakdown. It&#39;s based on analyzing experimental S-parameters under common-source and common-drain configurations, which allows to identify the location of the damage by inspecting asymmetry in the electrical response. Furthermore, the technique is compatible with radiofrequency two-port test fixtures exhibiting one of the terminals grounded, such as those used for characterizing microwave devices. Using the technique, two breakdown mechanisms are observed.

IRPS 2024 Main Conference

Assessing Non-Conducting Off-State Induced Hard Breakdown for PD-SOI MOSFETs using an RF Measurement Technique
