For memory and in-memory computing applications, the multi-level cell (MLC) is one of the most favorable characteristics of RRAM. However, achieving stable MLCs demands time-consuming programming strategy. This paper presents a novel programming algorithm, Adaptive Step Adjustment Programming (ASAP), implemented on 1Mb RRAM chips fabricated using 40nm CMOS technology. Our experimental results showcase remarkable improvement in 16-level MLC programming efficiency. The MLC retention characteristics exhibit good stability after 104 s thermal stress at 150 ℃.

IRPS 2024 Main Conference

ASAP: An Efficient and Reliable Programming Algorithm for Multi-level RRAM Cell
