Obtaining uniform silicon concentration, especially with low concentrations (ranging from 1x1016 cm-3 to 1x1018 cm-3) by molecular beam epitaxy (MBE) has been challenging due to the oxidation of silicon solid source in the oxide environment. In this work, Si doping of β-Ga2O3 (010) films by diluted disilane as the Si source is investigated using a hybrid plasma-assisted molecular beam epitaxy (hybrid-PAMBE). The impact of growth temperature, disilane source concentration, and disilane flow rate on Si incorporation was studied by secondary ion mass spectrometry. Uniform Si concentrations ranging from 3×1016cm-3 to 2×1019cm-3 are demonstrated. Si-doped β-Ga2O3 films with different silicon concentrations were grown on Fe-doped β-Ga2O3 (010) substrates. The electron concentration and mobility were determined using Van De Pauw Hall measurements. A high mobility of 135cm2/Vs was measured for an electron concentration of 3.4×1017cm-3 at room temperature.
