III-V materials nowadays are becoming a promising building block for nonlinear optics thanks to their significant nonlinear properties. MBE and MOCVD have been widely used to grow epitaxial films on various substrates. However, the difficulty in lattice matching, the constraint in substrate selection, the issue in epitaxial transfer aligning, and the cost in fabricating, become the barrier to applications. Here, we introduce a new thin-film epitaxial growth method, templated liquid phase (TLP) growth, to directly grow III-V semiconductor film on any substrate with single crystallinity, high uniformity, and high carrier mobility. As a demonstration, we choose lithium niobate (LiNbO3), a promising material widely used in nonlinear optics and acoustoelectric fields, as the substrate to grow patterned InAs layer. With this technology, we grow InAs in line-shape patterns with widths varying from 3 micron to 10 micron and lengths varying from 10 micron to 100 micron. Based on our measurements, the electron mobility reaches ~3500 cm2/Vs at 100K and ~2400 cm2/Vs at 300K. In prospect, TLP growth method can construct a platform to fabricate any desired patterns on any substrates in applications of nonlinear optics profit from the superior nonlinear properties of III-V semiconductors.

EMC 2023

Monolithic III-V on LiNbO3 for Nonlinear Optics Application

monolithic epitaxial growth

templated liquid-phase growth

iii-v semiconductors

lithium niobate
