Bismuth (Bi)-containing III-V semiconductor materials are attracting considerable interest due to their predicted non-trivial topological surface states and band inversion. These topological surface states (TSSs) have their spin locked with orbital momentum because of large spin-orbit coupling, presenting the high charge to spin conversion efficiency and application in spintronics. [1, 2] Previously, either Bi1-xSbx bulk growth was studied, [3] which is hampered by low Bi incorporation, or the focus was set on the growth of metallic Bi films on top of semiconductor substrates, [4] without highlighting the Bi-substrate interaction. However, it is vital to experimentally investigate the Bi-semiconductor interface and the potential formation of Bi-induced topological surface states, not just for spintronics application but also from the fundamental physics point of view. Here, we investigate the incorporation of Bi atoms into the semiconductor surface, thus increasing the local Bi content in the semiconductor and forming atomic-scale heterostructures in a controlled way. We will present multiple steps of Bi incorporation in the InSb(111)B surface using a combined study of scanning tunneling microscopy (STM), X-ray photoemission spectroscopy (XPS), and low energy electron diffraction (LEED). After cleaning the InSb(111)B surface from native oxide using atomic hydrogen, STM shows a 3X3 reconstruction, in agreement with previous studies. [5] We observe that Bi incorporation on a heated InSb(111)B substrate (Ts=250 C) initiates by forming a buckled triangular atomic arrangement. XPS of the Bi 5d core-level shows that Bi interacts with Sb by forming Bi-Sb bonds. Interestingly, the incorporation is self-limiting, i.e., the amount of Bi in a Bi-Sb configuration remains unchanged irrespective of deposition cycles for the heated sample. Further deposition of Bi at room temperature (RT) instead results in multi-layer thick Sierpinski-type defective triangles [6] comprising mainly metallic Bi. However, the Bi incorporation under the before-mentioned conditions occurs predominantly at random sites on the surface, hindering the formation of a large-scale symmetric surface layer. However, when Bi was deposited at RT, followed by an annealing step at 250 C for 15 minutes, a periodic (2X2) reconstructed surface was observed. XPS indicates that also this ordered 2X2 surface is characterized by Sb-Bi bonding, similar to the chemical state of the surface that results from Bi deposition at Ts=250 C (as mentioned above). Similar 2X2 reconstruction can be obtained if the sample is annealed (at Ts= 250 C) in-between any Bi deposition conditions. That shows that Bi bonded to Sb tends to stabilize in a 2X2 periodic surface structure of self-limiting bonding configuration. In summary, we present the formation of a controllable and ordered, atomically thin Bi-Sb layer on InSb which is highly promising for realizing 2D topological insulators on III-V semiconductor substrates. References: [1] S. Fragkos et al., Phys. Rev. Materials 5, 014203 (2021) [2] T. Campos et al., Phys. Rev. B 97, 245402 (2018) [3] D. Hsieh et al., Nature 452, 970 (2008) [4] Z. Liu, et al., Phys. Rev. Lett. 107, 136805 (2011) [5] J. Wever et al., Surf. Sci., 321, L225 (1994) [6] C. Liu et al., Phys. Rev. Lett., 126, 176102 (2021)

EMC 2023

Self-Limiting Formation of Bismuth-Induced Nanostructures on the InSb(111) Surface

x-ray photoemission spectroscopy (xps).

scanning tunnelling microscopy (stm)

bismuth-incorporation
