Permanents magnets, or hard ferromagnets, provide a “free” source of magnetic field, with no need of external power. Considering the integration with microsystems,
permanent micromagnets are critical components for the fabrication of microscale motors, generators, switches, pumps, acoustic speakers and energy harvester. Even though the
understanding of magnetism and magnetic materials has led to advancements in their magnetic properties [1], the application of permanent magnets in microsystems is still limited. The
reasons for that are: i) the methods for magnet fabrication at the macroscale (casting and powder processing) are fundamentally different to thin-film microfabrication approaches (physical
vapor deposition, chemical vapor deposition, electrochemical deposition); ii) even if microfabrication approaches are exploited, difficulties remain in depositing thick magnetic films (&gt; 1
μm) and issues due to process compatibility [2].
In this work, we present a process to integrate MEMS (MicroElectroMechanical Systems) and thick permanent magnets. We have designed test structures (Fig. 1) and optimized a process
to fabricate the devices. The optimizations concern: i) deposition of a micron-thick layer of a magnetic material; ii) thermal treatment to enhance the magnetic characteristics of the
material; iii) patterning technique employed to obtain micromagnets; iv) introduction of a passivation layer to protect the material from the subsequent process steps. An image of the final
fabricated device is shown in Fig.2. Examples of application of said process to devices for energy harvesting and magnetic sensing will be discussed.&lt;br&gt;

**References:**&lt;br&gt;

M. Sagawa, S. Fujimura, N. Togawa, Journal of Applied Physics, Vol. 55, p. 2083 (1984)&lt;br&gt;
D. P. Arnold, N. Wang, Journal of microelectromechanical systems, Vol. 18, p.1255 (2009)&lt;br&gt;

![](https://s3.eu-west-1.amazonaws.com/underline.prod/uploads/markdown_image/1/image/2e8453b58011aaaa96750f6eb42a03f7.png)

MMM 2022

Integration of hard magnetic layer in MEMS process
