We propose a geometric statistical model to describe stress-induced leakage current (SILC) as a function of trap density (Dot). We demonstrate how soft breakdown measured on smaller devices is controlled by a 2 traps percolation path and how its voltage dependence coincides with the 1 to 2 traps transition of SILC measured on larger devices. Finally, assuming the high-k as the breaking layer, we convert the 1-trap leakage current into Dot.

Combining SILC and BD statistics for low-voltage lifetime projection in HK/MG stacks

Gate oxide reliability face a big challenge in high temperature automotive application (auto-grade 0). In this paper, we fully discuss the physical mechanism of oxide trap interaction and point out the oxide reliability weakness. It is found the unexpected TDDB behavior at high temperature, include serious SBD, the relationship of voltage acceleration change, and non-linear temperature effect. In addition, the AC/DC effect found more obvious recovery effect. Finally, for mass production, we also import the confidence level usage to give a reasonable lifetime margin for mass production.

A Realistic Modeling Approach To Explain the Physical Mechanism of TDDB For Automotive Grade-Zero Applications

We propose a novel method of predicting electron and hole lateral diffusion in a charge trapping layer of 3D TLC NAND by which we can estimate the long-term lateral migration (LM) behavior in a short time. By monitoring the threshold voltage change (△Vth) of the select cell under various bias and temperature conditions, we observe that electron and hole lateral diffusivity matches well with the Poole-Frenkel (PF) model. The lateral diffusivity is extracted by measuring △Vth when the electrons and holes of neighboring cells reach the selected cell.

Electric Field Impact on Lateral Charge Diffusivity in Charge Trapping 3D NAND Flash Memory

Temperature-accelerated methods are generally used for lifetime evaluations in Flash memories products. However, in this article, an anomalous negative temperature dependence of erase-state threshold voltage (Vt) retention gain in post program/erase (P/E) cycled 3-D NAND Flash memories is reported for the first time, which would lead to a methodological problem of the conventional temperature-accelerated life-test approach. Based on our experiment results, the phenomenon is realized due to the combination of two physical mechanisms. Erase Vt gain at lower temperatures is mainly attributed to silicon nitride (SiN) trapped hole vertical loss via oxide trapped charges created by high P/E cycling stress. At higher bake temperatures, the influence of oxide trapped electron detrapping process is enhanced and Vt gain is therefore reduced. By performing a special experiment, the activation energy of the trapped electron detrapping process is extracted.

An Abnormal Negative Temperature Dependence of Erase-state Vt Retention Shift in 3-D NAND Flash Memories

In this paper, the long term data retention characteristics consisting of three main charge loss mechanisms, detrap, trap-assisted tunneling (TAT), and lateral migration (LM), are investigated in charge trap (CT) 3D NAND flash memory. Three mechanisms were completely separated through experiment design, and each activation energy (Ea) was extracted with Arrhenius model well. The detrap mechanism shows the largest Ea, followed by LM and TAT mechanisms. It is interesting that the contribution rate (CR) of each mechanism is related to time-constant (t) in the early part of bake time, and depends on the final charge loss in the latter part of bake time. It is inferred that the retention bottleneck is low program level state at high temperature and is high program level state at low temperature. TAT mechanism dominates the final charge loss regardless of temperature region and program level state. In addition, an effective method is proposed to suppress the LM effect.



Investigation of Retention Characteristics in a Triple-level Charge Trap 3D NAND Flash Memory

We present a detailed analysis of Off-state Time Dependent Dielectric Breakdown (TDDB) under non-uniform field performed in MOSFET devices from 28nm FDSOI, 65nm SOI to 130nm nodes. Oxide breakdown in thin gate oxide is characterized under DC stress with different gate-length LG and as function of drain voltage VDS and temperature. We show that the leakage current is a better monitor for TDDB dependence under Off-mode stress whereas a new modeling is proposed. It is found that Weibull slopes β are higher in PFET due large amount of injected hot electrons than in NFET when hot holes are involved.

New Modelling Off-state TDDB for 130nm to 28nm CMOS nodes

Be closer to real product operation, DC TDDB stress convert to AC TDDB could be one choice to wrestle with advanced node shrink limitation. The physical explanation of AC TDDB improvement is successfully interpreted through the analysis of oxide trap generation with HK/IL gate stack in advanced node FinFET technology using SILC spectrum methodology. It is found that AC TDDB improvement is due to more charge de-trap. NMOS show less shallow and deep electron trap generation on HK and PMOS show less hole trap generation on IL during AC waveform transition.

AC TDDB Analysis for HK/IL Gate Stack Breakdown and Frequency-dependent Oxygen Vacancy Trap Generation in Advanced node FinFET Devices by SILC Spectrum Methodology

This work shows that the complex dynamic-RON characteristics observed for highly scaled HEMT devices results from the similar capture/emission activation energies of the defects present in different epitaxial layers. This work also (i) presents an optimized experimental scheme for a detailed analysis of the different charge-trapping mechanisms in GaN-on-Si HEMTs, (ii) describes the charge-trapping kinetics over a wide range of temperatures using capture/emission time (CET) maps, and (iii) models the defect energy distribution in the AlGaN barrier by analytically deriving the 2D potential profile in the access region and combining it with the results from CET maps.

Interpretation and modelling of dynamic-RON kinetics in GaN-on-Si HEMTs for mmWave applications

We have investigated and report here for the first time time-dependent dielectric breakdown (TDDB) in 45-nm RFSOI n-channel floating body MOSFETs at cryogenic temperatures. DC constant voltage stress is applied at the gate while the substrate chuck temperature is varied from 300K down to 10K. While t63 decreases with increasing temperature, shape parameter β shows an inverted U-shaped behaviour which is explained using the bandgap model. Three levels of activation energy are seen for high, low and deep low temperatures where the activation energy decreases from high to deep low temperatures. The observed behaviour is further explained using the bandgap as per the percolation theory.

Deep Cryogenic Temperature TDDB in 45-nm PDSOI N-channel FETs for Quantum Computing Applications

The sub-THz spectrum between 100GHz and 300GHz is of great interest for achieving next generation 6G cellular network goals of ultra-high data rate, ultra-low latency and high sensing precision. Carrier frequencies &gt;100GHz create significant challenges, including higher losses, lower semiconductor device performance, and a smaller per element physical area that constrains circuit size, integration, power and thermal management. Semiconductor technologies with transistor performance &gt;500GHz are needed for improved efficiency, gain, noise and area at the front end of the 6G phased array radio. Advances in SiGe BiCMOS have the potential to increase silicon transistor performance while leveraging the cost and scale of mature high-volume silicon manufacturing for 6G sub-THz. Compound semiconductor technologies such as InP and GaN have the best front end performance at sub-THz. Advances in heterogeneous and monolithic integration with silicon are needed to address the cost and scale concerns of high frequency InP and GaN.  A comprehensive approach to reliability is essential in order to extract maximum performance without sacrificing reliability.
