We investigate and model the threshold voltage instabilities of 4H-SiC power MOSFETs at room and cryogenic temperatures, based on wide time range (from µs to ks) PBTI analysis. We show that for T &amp;gt; 200 K a stretched (log-like) de-trapping transient dominates the recovery kinetics, while at lower temperatures (down to 80 K) a fast exponential component is also visible. The charge de-trapping process is modeled as a distribution of traps spread over the midgap, that causes the threshold instability. Results indicate: i) one narrow gaussian energy distribution at the interface, visible at low temperature, which explains the exponential transient behavior for T &amp;lt; 200 K; ii) a broader distribution deeper in energy, that is considered to take into account the logarithmic de-trapping kinetics at higher temperatures and the threshold static shift with temperature. The proposed modeling framework can accurately reproduce the experimental results.

IRPS 2022 Main Conference

Analysis and Modeling of Vth Shift in 4H-SiC MOSFETs at Room and Cryogenic-Temperature

cryogenic temperatures

threshold voltage

The Electronic Materials Conference (EMC) is the premier annual forum on the preparation, characterization and use of electronic materials. This year’s event will feature a plenary session, topical sessions, a poster session and more.

EMC is coordinated with the Device Research Conference (DRC), which will be held during the same week, from June 20-23. This recognizes the strong interaction between device and electronic materials research and provides fruitful exchange of information between attendees of both Conferences.

![](https://assets.underline.io/uploads/markdown_image/1/image/eb26c24a18d5d1030616afa4f993cf89.png)

<a href="https://www.mrs.org/docs/default-source/meetings-events/mrs-conference-services/2021/emc-2021/2021-emc-program-at-a-glance-6-16-21.pdf?sfvrsn=e39f950c_4">Latest Program-at-a-Glance</a>

<a href="https://drive.google.com/file/d/1eiS1ao4p83VNy8xgHs3Rls7gTQjx7Rc4/view?usp=sharing">Full Program with Abstracts</a>

EMC 2021

We investigate and model the threshold voltage instabilities of 4H-SiC power MOSFETs at room and cryogenic temperatures, based on wide time range (from µs to ks) PBTI analysis. We show that for T &gt; 200 K a stretched (log-like) de-trapping transient dominates the recovery kinetics, while at lower temperatures (down to 80 K) a fast exponential component is also visible. The charge de-trapping process is modeled as a distribution of traps spread over the midgap, that causes the threshold instability. Results indicate: i) one narrow gaussian energy distribution at the interface, visible at low temperature, which explains the exponential transient behavior for T &lt; 200 K; ii) a broader distribution deeper in energy, that is considered to take into account the logarithmic de-trapping kinetics at higher temperatures and the threshold static shift with temperature. The proposed modeling framework can accurately reproduce the experimental results.

technical paper
