Spin Hall oscillator (SHO) is a promising spin torque oscillator (STO) having high durability due to a small driving current. However, conventional SHOs with in-plane precession (IPP) mode require bias-fields for stable oscillations [1-4], which are not favored in certain applications such as a neuromorphic computing [5]. Here, we propose and theoretically analyze a bias-field-free SHO with an in-plane hard axis and out-of-plane precession (OPP) mode by solving the macrospin Landau-Lifshitz-Gilbert-Slonczewski equation analytically and numerically. Fig. 1 shows the schematic structure of our two-terminal bias-field-free SHO. The SHO consists of a magnetic tunnel junction, a spin source layer, and a shunting resistance. Materials with a small spin Hall angle are also available for the spin source because the shunting resistance provides an in-plane charge current path for a spin current generation by the spin Hall effect. A bias-field-free OPP mode can be obtained by controlling a magnetic hard axis of free layer in the same direction of a spin polarization. In our simulations, the magnetic anisotropy was controlled by demagnetization coefficients without the loss of generality. Fig. 2 shows the typical simulation result of the magnetization dynamics in our SHOs. Bias-field-free oscillations were successfully observed. We also derived formulas for a critical current, a driving current and an oscillation frequency by using the saddle and constant energy approximations [6], and they were in good agreement with numerical simulation results. Furthermore, the drive current of our SHOs were almost ten times smaller than that of conventional bias-field-free STOs.References: [1]L. Liu, C. -F. Pai and D. C. Ralph, Phys. Rev. Lett., Vol. 109, p.186602 (2012) [2]Z. Duan, A. Smith and L. Yang, Nat. Commun., Vol. 5, p.5616 (2014) [3]V. E. Demidov, S. Urazhdin and H. Ulrichs, Nat. Mater., Vol. 11, p.1028 (2012) [4]V. E. Demidov, S. Urazhdin and A. Zholud, Appl. Phys. Lett., Vol. 105, p.172410 (2014) [5]J. Torrejon, M. Riou and F. A. Araujo, Nature, Vol. 547, p.428 (2017) [6]T. Taniguchi and H. Kubota, Phys. Rev. B, Vol. 93, p.174401 (2016)

MMM 2020

Bias-field-free spin Hall oscillator with an out-of-plane precession mode
