Historically, students of materials science and engineering were introduced to crystal chemical principles through examining physical models of simple crystals (typically metals or binary salts), latterly augmented by 3D visualisation of structures (the persistent interest in perovskites comes to mind). Both approaches have their strengths and weaknesses. Physical models cater well to tactile learners but are limited to simple lattices. Commonly, the concept of close packing is illustrated with large balls to demonstrate 2-layer hexagonal close packing (hcp) and 3-layer cubic close packing (ccp) with smaller balls occupying interstitial cavities (1). Such models are appreciated by students and feedback indicates improved appreciation of octahedral and tetrahedral co-ordination. A limitation of this approach is that interstitial sites are ‘hidden’ amongst the large balls, although this can be overcome through the use of transparent spheres (2). Ball and stick models remove some of these limitations, but are more appropriate for molecular chemistry, as they become rather intricate when dealing with ‘infinite’ lattices of even moderate complexity.

Computer-generated structure representations have the advantage of being readily scalable to larger classes, inexpensive and applicable to complex structures. Their use can also be integrated with crystal database extraction and introducing the basics of crystallographic information files (CIFs). However, the very ease of producing beautiful and dynamic drawings, especially with those packages that automatically locate and display the polyhedra can lead to a black-box exercise with poor educational outcomes. Nonetheless, such packages are de rigueur in crystal chemical research and students should be proficient in their use and the interpretation of topological relationships.

Precision polyhedral models bridge the gap between classical constructions from spheres or balls-and-sticks and contemporary computed representations. First, more complex structures can be assembled from polyhedral groupings. Second, the different topological connectivity between polyhedra (corner-, edge- face-sharing) becomes evident, as do changes in symmetry through displacive topological transformations. Third, the Wyckoff positions extracted from the CIFs can be readily identified, and finally, the physical models bear a striking resemblance to the 3D visualizations.

This video poster demonstrates the process and the value of exploiting close-packed kernels to explore the breadth of connectivity in several important structures. Using hemi-cuboctahedra the ccp kernel (a cuboctahedron) and the hcp kernel (a twinned cuboctahedron) are constructed. CIF for rutile (hcp), wurtzite (hcp), rhenia (ccp) and sphalerite (ccp) are drawn using 3D visualisation tools. Students then construct the polyhedral representations of these structures around the kernels.

Unfortunately, research concerning the synergistic benefits of the combined manipulation of physical and virtual models is sparse, but the anecdotal evidence is that a deeper appreciation of crystal chemical concepts results (3). No doubt students with different learning-strengths will benefit more-or-less from these complementary approaches, and for this reason, team learning where abstract thinkers produce the 3D visualisation and hands-on practitioners build the physical model can be especially instructive.

(1) Ma et al., Using Magnet-Embedded Silicone Balls to Construct Sable Models for Close-Packed Crystal structures, J. Che. Educ., 97, 4063-4068 (2020).
(2) Lenzer et al, Making it Clear: Exploring Crystal Structures by Constructing and Comparing See-Through Models. J. Chem. Educ. 2019, 96, 8, 1630–1639 (2019)
(3) Kelly, I Comparison of Virtual Models and Hands-on Models for Teaching Crystallography, (2001) Master Thesis, Purdue University


MATERIALS FOR HUMANITY (MH 21)

Precision Polyhedral Models for Crystal Chemical Instruction: Integrating Crystal Structure Databases and Enhancing the Appreciation of 3D Visualisation
