Singapore

Recent years witnessed a significant volume of research for understanding the simple physics in photodetection and its applications in energy and sustainability. Photodetectors are useful in variety of applications from consumer electronic devices to industrial and environmental monitoring, flame and gas sensing, space communication, proximity sensors, missile technology etc to name a few. The possibility of engineerable band gap brought semiconducting TMDC MoS2 as one of the prominent among the 2D layered material family for photodetection and gas sensing applications. In my presentation, I will explain the structural and optical features of the MoS2/AlN heterostructure device fabricated through pulsed laser ablation. A few layers of MoS2 were grown on commercially procured and AlN templated Si wafer in an evacuated PLD chamber by ablating locally prepared MoS2 target with KrF excimer laser. Both photovoltaic and photothermal responses are to be analyzed to account for the observed intensity-modulated and wavelength-dependent photoswitching in MoS2/AlN heterostructures. The self-powered response obtained in the device was attributed to the large difference in band gap values of the complementary materials in the binary system, their band alignment, and band bending. Raman spectrum analysis, XPS, XRR, photodetection, etc will be presented to reveal the physical features and structural characteristics of the heterostructure. A detailed account of the photodetection and switching mechanism will also be discussed.
Acknowledgment
Pius acknowledges the research grant TARE (TAR/2020/000241) by Science and Engineering Research Board (SERB), DST, Govt. of India to carry out research at Material Research Centre, Indian Institute of Science Bangalore.
Reference
[1] Clark, Jenny, and Guglielmo Lanzani. Nature Photonics 4, no. 7 (2010): 438-446.
[2] Fang, Huajing, Cheng Zheng, Liangliang Wu, Yi Li, Jian Cai, Mingxiang Hu, Xiaosheng Fang, Rong Ma, Qing Wang, and Hong Wang. Advanced Functional Materials 29, no. 20 (2019): 1809013.
[3]Lu, Xiaowei, Peng Jiang, and Xinhe Bao. Nature Communications 10, no. 1 (2019): 1-7.
[4][Singh Deependra Kumar, Rohit Pant, Arun Malla Chowdhury, Basanta Roul, Karuna Kar Nanda, and Saluru Baba Krupanidhi. ACS Applied Electronic Materials 2, no. 4 (2020): 944-953.


MATERIALS FOR HUMANITY (MH 21)

Photoswitching and self-powered response in PLD grown MoS2/AlN heterostructure photodetector
