We present a quantum-mechanical study of a B2-phase of Fe70Al30 alloy
with and without antiphase boundaries (APBs) with the {001} crystallographic
orientation of APB interfaces. Our motivation is to explain experimental
findings demonstrating a significantly higher magnetic flux density from
A2-phase interlayers at the thermally-induced APBs in this material
and suggesting that the ferromagnetism is stabilized by the disorder in
the A2 phase. Our investigation of sharp APBs (without any A2-phase interlayer)
indicates that they have moderate APB energies (~0.1 J/m2) and cannot explain the
experimentally detected increase in the ferromagnetism because they
often induce a ferro-to-ferrimagnetic transition. When studying
thermal APBs, we introduce a few atomic layers of A2 phase of Fe70Al30 into
the interface of sharp APBs. The averaged computed magnetic moment of Fe atoms
in the whole B2/A2 nanocomposite is then increased by 11.5% w.r.t. the B2 phase.
The A2 phase itself (treated separately as a bulk) has the total magnetic moment
even higher, by 17.5%, and this increase also applies if the A2 phase at APBs
is sufficiently thick (the experimental value is 2–3 nm). We link the changes
in the magnetism to the facts that (i) the Al atoms in the first nearest
neighbor (1NN) shell of Fe atoms nonlinearly reduce their magnetic moments
and (ii) there are on average less Al atoms in the 1NN shell of Fe atoms
in the A2 phase. These effects synergically combine with the influence
of APBs which provide local atomic configurations not existing in
an APB-free bulk. The identified mechanism of increasing the magnetic
properties by introducing APBs with disordered phases can be used as
a new designing principle when developing new magnetic materials.

MATERIALS FOR HUMANITY (MH 21)

Enhancing magnetism in Fe-Al alloys by increasing chemical disorder
