Silicon on Insulator is used extensively for its robustness in automotive applications.
X-FAB&#39;s BCD on SOI 180nm platform aims at high performance for HV applications and focuses on flexibility and ease of use.
It enables the integration of high voltage BCD devices for driving actuators and motors with high precision analog functions for sensor interface and signal processing. SOI in this context is relevant for its robustness such as latchup immunity and reduced high temperature leakage and also for its isolation properties.
In order to serve our foundry customers, the X-FAB 180nm BCD on SOI platform is highly modular and is fully supported by models, PDKs and design IPs.
When faced with particular operating range constraints, designers can select technology modules to optimize circuit performance for high power/high voltage interfaces.
Besides the traditional ON resistance for a given breakdown voltage, our recent development improved on the usability of the medium and high voltage options with devices ranging from 12V to over 300V. For each geometry the most suitable performance trade-off can be designed with fully characterized and modeled transistors for each voltage classe.
Our technologies are automotive qualified to grade 0 and characterized up to 175oC. We are extending the model validation up to 200oC allowing the design of sensor interfaces and drivers that will operate in a high temperature environment while allowing for dissipation and package thermal resistance.
To support the increase in digital content, non volatile memory IPs are provided either as embedded in the CMOS flow or with a dedicated SONOS module allowing denser implementation. For the SOI platform the memory IP designs are adapted for operation at hot temperature with a specific automotive friendly architecture.


ESSCIRC ESSDERC Educational Events

New results of Bipolar Cmos Dmos on Silicon On Insulator

soi bcd high-voltage nvm

The aim of ESSCIRC and ESSDERC is to provide an annual European forum for the presentation and discussion of recent advances in solid-state devices and circuits.
The level of integration for system-on-chip design is rapidly increasing.

This is made available by advances in semiconductor technology. Therefore, more than ever before, a deeper interaction among technologists, device experts, IC designers, and system designers is necessary. ESSCIRC and ESSDERC are governed by a common Steering Committee and share Plenary Keynote Presentations and Joint Sessions bridging both device and circuit communities.

Highlights:
* 3 joint keynote presentations
* 3 keynote presentations ESSCIRC
* 3 keynote presentations ESSDERC
* Invited papers with overall coverage of all aspects of advanced devices and circuits
* Presentation of IEEE and ESSCIRC/ESSDERC Awards
* Educational Events

JOINT PLENARY talks live broadcast: September 13, 2021<br>
ESSCIRC and ESSDERC KEYNOTE talks live broadcast: September 15, 2021<br>
LIVE Q&A INTERACTIVE sessions for all Conference Technical sessions: September 14 – 16 – 17, 2021<br>
LIVE Q&A INTERACTIVE sessions for all Educational Events: September 20-21-22, 2021<br>
(on demand videos available from September 6 until November 30, 2021)

**Please see here for the [ESSCIRC Guide](https://drive.google.com/file/d/10dghzuv4aQBty4QfTIY9Q8hXyqsue8Le/view?usp=sharing), [ESSDERC Guide](https://drive.google.com/file/d/10dx9y2tm9cHPDa4upNUYjfXCf44aPry5/view?usp=sharing), and the [Program at a Glance](https://drive.google.com/file/d/10eU0OLTXEpiNzI5hkqv4mSr43T8cedPP/view?usp=sharing)**

Please register for educational events at the following link: https://www.registerme.eu/event/esscirc-essderc-2021/

Please register for the ESSCIRC/ESSDERC Educational Events to join the event.

The Educational Events of ESSCIRC ESSDERC 2021.

Silicon on Insulator is used extensively for its robustness in automotive applications.
X-FAB's BCD on SOI 180nm platform aims at high performance for HV applications and focuses on flexibility and ease of use.
It enables the integration of high voltage BCD devices for driving actuators and motors with high precision analog functions for sensor interface and signal processing. SOI in this context is relevant for its robustness such as latchup immunity and reduced high temperature leakage and also for its isolation properties.
In order to serve our foundry customers, the X-FAB 180nm BCD on SOI platform is highly modular and is fully supported by models, PDKs and design IPs.
When faced with particular operating range constraints, designers can select technology modules to optimize circuit performance for high power/high voltage interfaces.
Besides the traditional ON resistance for a given breakdown voltage, our recent development improved on the usability of the medium and high voltage options with devices ranging from 12V to over 300V. For each geometry the most suitable performance trade-off can be designed with fully characterized and modeled transistors for each voltage classe.
Our technologies are automotive qualified to grade 0 and characterized up to 175oC. We are extending the model validation up to 200oC allowing the design of sensor interfaces and drivers that will operate in a high temperature environment while allowing for dissipation and package thermal resistance.
To support the increase in digital content, non volatile memory IPs are provided either as embedded in the CMOS flow or with a dedicated SONOS module allowing denser implementation. For the SOI platform the memory IP designs are adapted for operation at hot temperature with a specific automotive friendly architecture.


technical paper

5G standards effective deployment drives considerable technology challenges and implications on mobile devices design and requires innovative solutions to solve them.
At the RF Front End Modules (FEM) level, the usage of new frequency bands, the complex use of the frequency bands (Carrier Aggregation, MIMO, QAM) and the coexistence with 4G networks are challenging the limits of existing acoustic filter technologies.
A promising approach combining a thin single crystal LiTaO3 layer bonded on a Silicon substrate - so called Piezo On Insulator (POI) – together with the existing Surface Acoustic Wave (SAW) filter technology, enables to take advantage of guided waves that do not suffer from any radiation leakage. This SAW on POI approach will extend the use of the existing SAW technologies for higher performance integrated acoustic devices.
Triggered by the 5G filter market demand, the Smart CutTM technology has enabled high performance POI substrates supply chain in volume manufacturing, and paves the way to new design approaches for many applications beyond the Smartphone market.


Smart CutTM Piezo On Insulator (POI) substrates for high performance integrated acoustic devices

The IPCEI program at GF includes innovation along all technology readiness levels (TRLs). One example for very low TRL is the Reconficurable FET based on Schottky Barriers, close to 22FDX-processing. It enables camouflaging circuits for security applications, by e.g. providing NAND or NOR type cells, that can not be identified by reverse engineering. Another example is the development of a mmWave-variant of 22FDX allowing for operation frequencies typically in the 28-80 GHz regime, but also ranging up to 140 GHz. Characterisation of devices up to 3-4 times the operational frequency, a prerequisite for operation of the devices at these frequencies and showcases in the GHz regime for auto-Radar, 5 G and imaging radar are shown. These are just two examples, how the energy efficient 22FDX-technology at GF is enrichened by specialized variants and applications-specific- features.

Novel devices for security and showcases for mmwave with 22FDXTM

STMicroelectronics has developed a new generation of 40nm CMOS technology with embedded Non Volatile Memory targeted to support advanced Microcontrollers platforms. The presentation will briefly describe the very first implementation done with a standard Flash memory with high density but limited granularity (sector erase). We’ll then detail a second step, with a new NVM cell (eSTMTM) integrating a vertical select transistor to offer density similar to standard flash, but better erase control and granularity, that have been integrated in different IP blocks to suit MCU requirements. A latest step, will then be explained, showing further area reduction, as well as some perspective for generation ahead. From a circuit point of view, General Purpose MCUs done, with the initial technology, include a dual core for optimized performance and pass the 1000 DMips mark, while a derived version, using the optimized eSTMTM NVM cell, offer a 30% power consumption reduction. For secure MCU, 3 main applications have been targeted using the 40nm eSTMTM technology: circuit for contactless payment cards with biometry, harvesting enough energy to support a finger print sensor and verification, a circuit for embedded SIM with large NVM to allow high security loading and storage of virtual SIM cards and finally a combined embedded Secure Element and NFC controller (using the smallest eSTMTM cell) to support contactless applications in mobile phone such as payment, access control… Market for each applications represents hundreds of millions of circuits every year requiring robust, reliable and cost effective eNVM technologies.

Advanced Embedded Non-Volatile Memory solutions for General Purpose & Secure Microcontrollers

To address the increasingly challenging requirements of the RF front-end (RFFE) for 5G and also anticipated requirements for 6G, the 3D heterogeneous integration of GaN HEMT coupons on a RF-SOI technology is sought for combining the advantages of a high performance RF component and a capable Si based platform. Integration is performed at the transistor level rather than at a functional block level with conventional packaging methods. High performance RF passives, analogue, digital, and I/O functionality is performed by a 130nm RF-SOI technology with Cu and thick Cu metallurgy. GaN HEMT devices are instantiated as necessary to achieve design targets. Several examples of design innovation have been recently demonstrated by X-FAB including a 5.9-7.1GHz High-Linearity LNA, where the first stage cascode combines a HEMT and a Si NMOS exploiting higher output power and linearity of GaN. The second example is a SPST switch, where reduced insertion losses were observed in comparison to GaN on Si as a benefit of the integration method and also a significantly larger power handling capability than a Si counterpart. This discussion will include the present status and remarks on the future of this enabling technology.

multi-technology wafer level integration for RFFE applications

Both in Mobile and High-performance Computing (HPC) applications, efficient power supply of the processors was and is still being a big challenge for designers. Indeed, for these applications the power consumption is increasing while the power supply voltage is decreasing in alignment with the latest technological scaling. Thus, lowering and flattening the Power Distribution Network (PDN) impedance is more than ever important to mitigate the voltage fluctuation, the resonance and anti-resonance peaks caused by the PDN’s components. Such optimization is done by tuning the features of the different decoupling capacitors used along the power path from the power supply down to the processor. In this presentation, the benefits of using Low ESL silicon capacitors are demonstrated and compared to existing classical decoupling solutions. These components bring unprecedented design flexibility and significant improvements by reducing the voltage drop and enabling very low and flat PDN impedance.

Low ESL Ultra-thin silicon capacitors for PDN applications

Microelectronics plays a key role in fighting against global warming and preparing the world for the “post carbon age”. The performance of novel electronic based systems is constantly increasing by consuming less energy. This can be only achieved by novel systems that are designed in a holistic approach (Chip, passive components, package). The electronic package and interconnect solutions are contributing to these goals in a significant way. Besides this product focused potential for green electronics production and manufacturing of those is offering significant potential as well. Novel methods with respect to sustainable manufacturing have been achieved in this field and is contributing to reduce resource consumption in during production of electronic based systems of the future. These novel PCB and Packaging solutions as well as sustainable production concepts for them are under development in AT&S under IPCEI Microelectronic Project and will be presented in this talk.

PCB and packaging solutions for Green electronics

The usual amounts of data continue to grow exponentially. ICT currently consumes around 4% of the world's energy. Therefore one of the goals of the EU project “IPCEI” is a significant improvement the carbon footprint of digitization with the help of innovative Power semiconductors. In one example this goal will be addressed by increasing efficiency using the future generations of gallium nitride (GaN) technologies and housings for the electronics industry in Europe. In addition to circuit breakers for highly efficient energy conversion, inexpensive GaN on silicon high-frequency technologies will be developed, which accelerate the 5G expansion. Due to the large energy requirement, an efficiency improvement of only one percentage point results in a saving of approx. 10 megatons of CO2.
In this way, ICT can not only make many applications more “gree”, it can also become more “green” itself.

Power electronics for Green ICT

Power modules play a main role in traction inverter applications. They control engine speed and torque, regulating the energy flow between battery and motor. Due to the demanding electric and reliability performances requested by end costumers, semiconductor devices based on wide band gap compound are introduced in novel power modules. To support such device developments, there is the need to set a robust and accurate experimental methodology that shall be supported by numerical models. The targets are the prediction of thermal performance and the reliability forecast. In this framework, it has been proposed a dedicated flow to thermally characterize a multi-chip SiC MOSFET power module for automotive applications. Body-diode drop voltage has been selected as the temperature sensitive electric parameter to monitor the average junction temperature for thermal impedance measurements. Finite element model has been employed to predict temperature distribution due to device self-heating, referring to the previous characterization for the calibration of the numerical model. Once the thermal simulation methodology has been set, module temperature during inverter operations can be calculated, collecting temperature history profile into some loading conditions using a Rainflow-like approach. The several loading cases have been characterized by different temperature swing and cycle time. These classified data can be considered to evaluate lifetime duration due to selected failure mechanisms , supporting the definition of the most proper durability assessment for the application-relevant failure modes.

Structural characterization and simulation of a direct-cooled power module

After more than 35 years from its first conception and in the year of the recognition with the IEEE milestone, the Smart Power BCD technology is still evolving continuously and rapidly to serve at best the application requirements of new and changing markets.
As stated in the IEEE milestone for “Multiple Silicon Technologies on a Chip, 1985”, STMicrolectronics pioneered the super-integrated silicon-gate process combining Bipolar, CMOS and DMOS (BCD) transistors in single chips for power-demanding applications.
The markets currently requiring faster and higher technology evolutions are the Personal Electronics, bringing needs of wireless charging and power management, the Industrial, asking for more efficient power conversion, and the Automotive, where new challenges come from the battery management and inverter functions in Electric Vehicles and from Autonomous Driving. To meet those market requirements, the Smart Power BCD roadmap is following three key directions: digital processing capability increase (announced 40nm node with embedded non-volatile memory solutions), evolution to higher power and voltage (up to 10kV on-die galvanic isolation) and customization by application.
We will walk along these three evolution paths, presenting their technology features and related product examples.

The Smart Power BCD evolution in the year of the IEEE milestone

AP&S wet process development on SiC wafers started in 2015 and was initiated by an inquiry from one of the worldwide leading semiconductor manufacturers in Europe. This one was faced with the task of introducing a new production line for microchips based on SiC for a new progressive automotive application. The goal to achieve efficient, high-yield and cost-effective production for SiC products thus has come in focus. One important step in this overall production process has been the reliable and cost-efficient wet processing. The joint development between the semiconductor manufacturer and AP&S, in particular the Demo Center, thus began. This journey took us from metal lift-off process to metal etching processing with endpoint detection on singlewafer application to high-volume batch processing. In this presentation both the changes in the semiconductor manufacturing processes and the solutions derived from them will be presented. Clear breakdowns of the various process data, parameters and conditions will be shown including a detailed overview of the development on SiC from 2015 to 2021.
