**Abstract:**

A fast charge loss during short time retention operation was observed in word-line stacked 3-D NAND flash memory, and the origin of the fast charge loss was comprehensively evaluated. Using a fast-response pulse I-V system, the fast charge loss behaviors from lateral and vertical migration of trapped charges were thoroughly investigated and measured at various program/erase levels and temperatures in solid and checkerboard pattern.

ESSCIRC ESSDERC 2021

Vertical and Lateral Charge Losses During Short Time Retention in 3-D NAND Flash Memory

checkerboard pattern

solid pattern

vertical migration

lateral migration

flash memory

fast charge loss

retention
