**Please read the paper on the following link:**

https://1worldcontent.com/ess/9213.pdf

**Abstract:**

In this work, a wafer-scale fabrication of biologically sensitive Si nanowire FET is demonstrated for pH sensing and electrical detection of DNA hybridization. Based on conventional “top-down” CMOS compatible technology, our bioFETs explore a wide range of design (nanowires (NW), nanoribbons (NR), and honeycomb (HC) structures) with opening access scaled down to only 120 nm. After device fabrication, IDS-VBG transfer and IDS-VDS output characteristics show a conventional n-type FET behavior with an ION/IOFF value higher than 105, as well as an increase of threshold voltage (VTH) as the NW width is reduced. Then, using a capacitive coupling in our dual-gated Si bioFETs, the pH sensitivity is enhanced with a pH response up to 600 mV/pH. Finally, the increase of threshold voltage of n-type SiNWs due to the hybridized target DNA molecules is successfully detected

ESSCIRC ESSDERC 2021

Wafer-Scale Fabrication of Biologically Sensitive Si Nanowire FET: From pH Sensing to Electrical Detection of DNA Hybridization

isfet

biosensor

nanowire

cmos

sensor

health

Welcome to Delaware State University’s Annual Summer Research Symposium, and thank you for attending! Our symposium represents the culmination of students’ summer experiences in research at Delaware State University. This event showcases the work of college students working on faculty-led research projects, as well as middle and high school students experiencing research for the first time working in research groups. Whatever the case, this summer has been a unique experience for the students, and we hope a transformative one. Even for students who are not planning a career in scientific research, their summer experience has given them skills they will draw on for years to come.
 Please join us on the mainstage and in Gather for the live event, and visit the recorded poster presentations any time.
 The student participants and organizers of the various summer programs at DSU would like to thank all of the research mentors who guided our summer program participants. There were many DSU faculty, graduate students, and other research and program staff who gave their time and energy to help our students have a fun and educational summer experience. Without their generosity and patience these summer programs would not be possible.
 For the research participants, we hope that you will maintain contact with your research mentors and colleagues. Science is a relatively small community made up of disciplinary “neighborhoods”. If you continue to work in a discipline, the other folks in that discipline will be like your neighbors that you run into regularly. Staying in contact with them will help you keep up with the news of the neighborhood, and open doors to educational and career opportunities. Whether you continue in science or take a different career path, for this summer you have been part of the world of research, and you will benefit from that perspective for the rest of your life.

Please register for the DSU Summer Research Symposium 2021 to be able to access the content.
If you have already registered, please login with the same email you used to registered for the Conference.

DSU Summer Research Symposium 2021

Welcome to Delaware State University’s Annual Summer Research Symposium, and thank you for attending!

technical paper

The aim of ESSCIRC and ESSDERC is to provide an annual European forum for the presentation and discussion of recent advances in solid-state devices and circuits.
The level of integration for system-on-chip design is rapidly increasing.

This is made available by advances in semiconductor technology. Therefore, more than ever before, a deeper interaction among technologists, device experts, IC designers, and system designers is necessary. ESSCIRC and ESSDERC are governed by a common Steering Committee and share Plenary Keynote Presentations and Joint Sessions bridging both device and circuit communities.

Highlights:
* 3 joint keynote presentations
* 3 keynote presentations ESSCIRC
* 3 keynote presentations ESSDERC
* Invited papers with overall coverage of all aspects of advanced devices and circuits
* Presentation of IEEE and ESSCIRC/ESSDERC Awards
* Educational Events

JOINT PLENARY talks live broadcast: September 13, 2021
ESSCIRC and ESSDERC KEYNOTE talks live broadcast: September 15, 2021
LIVE Q&A INTERACTIVE sessions for all Conference Technical sessions: September 14 – 16 – 17, 2021
LIVE Q&A INTERACTIVE sessions for all Educational Events: September 20-21-22, 2021
(on demand videos available from September 6 until November 30, 2021)

**Please see here for the [ESSCIRC Guide](https://drive.google.com/file/d/10dghzuv4aQBty4QfTIY9Q8hXyqsue8Le/view?usp=sharing), [ESSDERC Guide](https://drive.google.com/file/d/10dx9y2tm9cHPDa4upNUYjfXCf44aPry5/view?usp=sharing), and the [Program at a Glance](https://drive.google.com/file/d/10eU0OLTXEpiNzI5hkqv4mSr43T8cedPP/view?usp=sharing)**

To access ESSCIRC ESSDERC 2021, you must pre-register for the conference.  Instructions on how to access the event will be provided directly to attendees and included on the ESSCIRC ESSDERC conference website. [Register now](https://www.esscirc-essderc2021.org/).

Please register for the ESSCIRC conference to join the event.

The aim of ESSCIRC and ESSDERC is to provide an annual European forum for the presentation and discussion of recent advances in solid-state devices and circuits.
The level of integration for system-on-chip design is rapidly increasing.

This is made available by advances in semiconductor technology. Therefore, more than ever before, a deeper interaction among technologists, device experts, IC designers, and system designers is necessary. ESSCIRC and ESSDERC are governed by a common Steering Committee and share Plenary Keynote Presentations and Joint Sessions bridging both device and circuit communities.





**Please read the paper on the following link:**

https://1worldcontent.com/ess/9304.pdf

**Abstract:**

In this work, a 10b 400MS/s single-channel SAR ADC is reported. Without an auxiliary sub-ADC, a subranging architecture is proposed, where only one comparator is used with the subsetted capacitive DAC (CDAC), eliminating the mismatch of comparators and saving area. For the subranging process, a partial detect-and-skip (PDAS) switching scheme is proposed, which improves both power efficiency and linearity without delay overhead. In addition, the dynamic logic circuits, including dynamic asynchronous loop (DAL) and dynamic SAR logic (DSL), are improved to reduce the power and logic propagation delay. Fabricated in a 40 nm CMOS process, this single-channel prototype operates at an enhanced sampling rate of 400 MS/s. At Nyquist, 56.4 dB SNDR and 73.1 dB SFDR are achieved. The ADC draws 3.46mW from a single 1.2V supply, leading to a Walden FoM of 16.0fJ/ conversion-step.

A 9.08 ENOB 10b 400MS/s Subranging SAR ADC with Subsetted CDAC and PDAS in 40nm CMOS

**Please read the paper on the following link:**

https://ieeexplore.ieee.org/document/9204647

**Abstract:**

This paper provides guidelines to design porous silicon layers regarding optimization of small-signal properties in passive structures for RF: insertion loss and cross talk. Results are based on high frequency measurements on 200 mm wafers and electromagnetic simulations up to 40 GHz. Using substrate resistivity below 1 ohm.cm allows the best trade-off with minimized porous silicon thickness.

Influence of Substrate Resistivity on Porous Silicon Small Signal RF Properties

**Please read the paper on the following link:**

https://ieeexplore.ieee.org/document/9186848

**Abstract:**

To enable CMOS compatible GaN HEMTs for the next generation of communication systems (5G and beyond), a low gate resistance is of great importance since it directly affects the RF power gain and fMAX of the transistor. In this paper, the impact of various gate-metal stacks on the gate resistance and RF performance of the devices is studied. The optimized Ti-free gatemetal process leads to fMAX enhancement up to ~ 50% for devices scaled down to 0.32μm gate lengths. The gate resistance for the Tshaped gate is modelled from S-parameters and validated on various gate field plate geometries. The tradeoff between the gate resistance and parasitic capacitance in GaN HEMTs is highlighted in this case.

Analysis of Gate Metal Resistance in CMOS Compatible RF GaN HEMTs

**Please read the paper on the following link:**

https://ieeexplore.ieee.org/document/9146558

**Abstract:**

In this paper, an ultra-broadband D-band wireless front-end receiver (RX) in 45nm CMOS SOI is proposed. It achieves a Noise Figure of 8 dB, a Gain of 16 dB, a 3 dB bandwidth of 25 GHz, and occupies a compact area of 2 mm2. To our knowledge, for the first time, the required millimeter-wave Local Oscillator signal is generated on-chip. Furthermore, 108 Gb/s data-rate is demonstrated by receiving and demodulating a signal composed of 10×2.16 GHz channels with -40 dBm average power and 64 QAM modulation. With a consumption of 200 mW from a 1-V voltage supply, the proposed RX achieves an energy efficiency of 1.8 pJ/bit

A 108 Gb/S 64-QAM CMOS D-Band Rx with Integrated Lo Generation

**Please read the paper on the following link:**

https://ieeexplore.ieee.org/document/9178366

**Abstract:**

In this paper, an ultra-broadband D-band wireless front-end transmitter (TX) in 45 nm CMOS SOI is proposed. Based on channel bonding and 64-QAM modulation, it achieves 84.8 Gb/s data-rate by combining 8×2.16 GHz baseband channels. The eight baseband channels are aggregated at Intermediate Frequency (IF) in two sets of four channels and then up-converted to two adjacent sub-bands at D-band. The required millimeter-wave Local Oscillators (LO) are generated on-chip. The Intermediate Frequency band is 57.96 GHz to 66.66 GHz, and the considered transmission band is from 140.895 GHz to 158.265 GHz. The presented TX integrates two up-converter mixers, two power amplifiers and an on-chip power combiner in addition to the two LO generator with a total DC power consumption of 420 mW from a 1-V voltage supply, and occupies a compact active area of 2.98 mm2.

A 84.48Gb/S 64-QAM CMOS D-Band channel-Bonding Tx front-End with Integrated multi-Lo Frequency Generation

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9197.pdf

**Abstract:**

We here report a joint experimental and theoretical analysis of polarization switching in ferroelectric tunnel junctions. Our results show that the injection and trapping of charge into the ferroelectricdielectric stack has a large influence on the polarization switching. Our results are relevant to the physical understanding and to the design of the devices, and for both memory and memristor applications.

Polarization Switching and Interface Charges in BEOL Compatible Ferroelectric Tunnel Junctions

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9167.pdf

**Abstract:**

Magnetic Tunnel Junctions (MTJs) constitute thenovel memory element in STT-MRAM, which is ramping toproduction at major foundries as an eFlash replacement. MTJswitching exhibits a stochastic behaviour due to thermal fluctu-ations, which is modelled by s-LLGS and Fokker-Planck (FP)equations. This work quantifies the effect of thermal noise,and proposes and benchmarks a new formulation for MTJinitial conditions to accurately match thermal noise results fromstatistical simulation. Further, Finite Volume Method (FVM) andanalytical solvers for the FP equation are implemented andbenchmarked. To deploy an MTJ model for circuit design, itmust be calibrated against silicon data. To address this challenge,this work presents a scheme to fit MTJ parameters to a given setof measured current, switching time and error rate data points.

A Fokker-Planck Solver to Model MTJ Stochasticity

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9251.pdf

**Abstract:**

A semi-empirical model for the optical properties of SiGe alloys is proposed, based on physical considerations and the summation of Tauc-Lorentz and parametric oscillators. The key parameters of the oscillators are intuited from the optical transition and the symmetry points in the band structure. The model is fitted on extensive experimental data, for different temperatures, germanium concentrations and for both unstrained and strained on (100) Silicium wafer cases. This model can be used in optical simulation tools, in order to help the design of optoelectronic devices based on SiGe materials.

Semi-Empirical Model for Optical Properties of Si₁−xGex Alloys Accounting for Strain and Temperature

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9265.pdf

**Abstract:**

This paper presents a new method to reliably simulate the PDE and jitter for realistic 3D device simulations of SPAD devices. This method is based on the use of electric field lines to mimic the carriers\' trajectories, which allows the transformation of a 3D problem into a multitude of 1D problems. This idea is applied to the McIntyre model for breakdown avalanche probability to calculate PDE, but also for jitter prediction using a dedicated advection-diffusion model. The results obtained numerically are compared with an extensive series of measurements and show a good agreement on a wide variety of device designs.

Comprehensive Modeling and Characterization of Photon Detection Efficiency and Jitter in Advanced SPAD Devices

"**Please read the paper on the following link:**

https://1worldcontent.com/ess/9226.pdf

**Abstract:**

Spin-Transfer Torque Magnetic Tunnel Junctions (STT-MTJ) are devices featuring stochastic properties. They are promising candidates for non-volatile memory or true random number generators. To design reliable hybrid CMOS circuits including STT-MTJs, one needs to use a compact model accounting for its stochasticity in the circuit simulations. This paper proposes a compact model that accurately mimics the MTJ stochastic switching behavior and meets the needs of fast execution time. The relevance of such a model together with its fast execution velocity are illustrated with a bitstream generator.
