**Please read the paper on the following link:**

https://1worldcontent.com/ess/9042.pdf

**Abstract:**

This paper presents a systematic design framework for ADC optimization. Our emphasis is on a robust design that is highly repeatable, which is driven by a deep understanding of the behavior of circuit building blocks. A 10 b 500 MS/s single-channel SAR ADC designed in this framework displays uniform performance for inputs up to 2 GHz at state-of-the-art FoM, which demonstrates the power of design based on analytical expressions.

ESSCIRC ESSDERC 2021

A Tutorial on Systematic Design of CMOS A/D Converters: Illustrated by a 10 b, 500 MS/s SAR ADC with 2 GHz RBW

jitter

sample and hold

regenerative comparator

analog-to-digital converter

systematic design

harmonic distortion

The aim of ESSCIRC and ESSDERC is to provide an annual European forum for the presentation and discussion of recent advances in solid-state devices and circuits.
The level of integration for system-on-chip design is rapidly increasing.

This is made available by advances in semiconductor technology. Therefore, more than ever before, a deeper interaction among technologists, device experts, IC designers, and system designers is necessary. ESSCIRC and ESSDERC are governed by a common Steering Committee and share Plenary Keynote Presentations and Joint Sessions bridging both device and circuit communities.

Highlights:
* 3 joint keynote presentations
* 3 keynote presentations ESSCIRC
* 3 keynote presentations ESSDERC
* Invited papers with overall coverage of all aspects of advanced devices and circuits
* Presentation of IEEE and ESSCIRC/ESSDERC Awards
* Educational Events

JOINT PLENARY talks live broadcast: September 13, 2021<br>
ESSCIRC and ESSDERC KEYNOTE talks live broadcast: September 15, 2021<br>
LIVE Q&A INTERACTIVE sessions for all Conference Technical sessions: September 14 – 16 – 17, 2021<br>
LIVE Q&A INTERACTIVE sessions for all Educational Events: September 20-21-22, 2021<br>
(on demand videos available from September 6 until November 30, 2021)

**Please see here for the [ESSCIRC Guide](https://drive.google.com/file/d/10dghzuv4aQBty4QfTIY9Q8hXyqsue8Le/view?usp=sharing), [ESSDERC Guide](https://drive.google.com/file/d/10dx9y2tm9cHPDa4upNUYjfXCf44aPry5/view?usp=sharing), and the [Program at a Glance](https://drive.google.com/file/d/10eU0OLTXEpiNzI5hkqv4mSr43T8cedPP/view?usp=sharing)**


To access ESSCIRC ESSDERC 2021, you must pre-register for the conference.  Instructions on how to access the event will be provided directly to attendees and included on the ESSCIRC ESSDERC conference website. [Register now](https://www.esscirc-essderc2021.org/).

Please register for the ESSCIRC conference to join the event.

The aim of ESSCIRC and ESSDERC is to provide an annual European forum for the presentation and discussion of recent advances in solid-state devices and circuits.
The level of integration for system-on-chip design is rapidly increasing.

This is made available by advances in semiconductor technology. Therefore, more than ever before, a deeper interaction among technologists, device experts, IC designers, and system designers is necessary. ESSCIRC and ESSDERC are governed by a common Steering Committee and share Plenary Keynote Presentations and Joint Sessions bridging both device and circuit communities.





technical paper

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9152.pdf

**Abstract:**

A ML based framework is presented to predict the formation and structure of defect in amorphous structures, aiming at reducing the computational costs which these studies require. The framework is applied to the prediction of hydroxyl E\' center defects in amorphous silicon dioxide. The results demonstrate a competitive level of accuracy, while being computationally inexpensive, when compared to DFT.

Machine Learning Prediction of Defect Structures in Amorphous Silicon Dioxide

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9266.pdf

**Abstract:**

It is well established that oxide defects are a major threat concerning the reliability of electronic devices. Point defects like the oxygen vacancy and hydrogen related defects like the hydrogen bridge and the hydroxyl-E\' center can trap charges from the Si substrate during operation. Here we present a statistical study of parameters by analyzing 144 defects of each type in amorphous SiO2 . We use density functional theory in conjunction with a hybrid functional to provide a large and accurate dataset of defect parameters such as the relaxation energy or the charge transition level and link them to bias temperature instability in nMOSFET devices.

Statistical Ab Initio Analysis of Electron Trapping Oxide Defects in the Si/SiO2 Network

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9264.pdf

**Abstract:**

This work presents a new method of noise model implementation for circuit simulations, which enables the generation of Lorentzian-type spectra. The importance of Lorentzian noise modeling is explored in contrast to classic 1/f or Random Telegraph Noise (RTN) modeling, in terms of PSD, total noise power, and device-to-device noise variability reproduction, through analysis of experimental data. The Verilog-A modeling methods for both types of Lorentzian noise are demonstrated and validated, using a Lambert-W function charge-based drain current model. Finally, fundamental digital and analog circuits such as the Ring Oscillator are used to showcase the usefulness and applicability of the “VERILOR” model in circuit noise simulations.

VERILOR: A Verilog-A Model of Lorentzian Spectra for Simulating Trap-Related Noise in CMOS Circuits

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9260.pdf

**Abstract:**

This paper presents reliability assessment of basic integrated circuits designed for analog and RF applications based on extensive circuit simulations using the aging compact model, HiCuM-AL v3.0, dedicated to SiGe HBTs. The physic-based aging compact model implemented within HiCuM model is based on trap generation-annihilation mechanisms as well as the Fick hydrogen diffusion law. The model has been validated against results from HBT aging tests under various stress conditions followed by aging model parameter extraction. Due to its extensive use in integrated circuit blocks, different current mirror configurations subjected to mixed-mode stress conditions are studied and analyzed in order to quantify the impact of HC degradation on individual HBTs as well as on overall circuit performances.

Impact of Hot Carrier Degradation on the Performances of Current Mirrors Based on a 55 nm BiCMOS Integrated Circuit Technology

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9230.pdf

**Abstract:**

This paper presents the analog predistortion abilities to linearize power amplifiers, operating both for satellite and mobile applications. A design example is done in Ku-band downlink applications with an integrated reflector-based analog predistortion. The proposed solution is a two cells nonlinear load-based AM/AM and AM/PM generation circuit made in a 130nm BiCMOS technology. The measurements performed for different biasing voltages and at different frequencies result in a gain compensation range between 0 dB and 9 dB and a phase compensation range between 0 and 50°. The size of each cell is 0.2 mm² and its total maximum power consumption is as low as 9 mW

Fully Integrated Reflector-Based Analog Predistortion for Ku-Band Power Amplifiers Linearization

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9234.pdf

**Abstract:**

A broadband 3-stage pseudo-differential SiGe power amplifier, fabricated in an experimental 130 nm SiGe BiCMOS technology with ft/fmax of 470/650 GHz, is presented in this paper. Coupled-line matching networks with optimized impedance ratios are used to maximize bandwidth and output power while maintaing flat power gain and group delay for wireless communications applications. The amplifier provides a maximum small-signal power gain of 17.9 dB and a peak Psat/OP1dB of 6.7/5.2dBm, respectively. The measured small-signal and saturated power 3-dB bandwidth cover 59 GHz (239-298~GHz) and 89 GHz (226-315~GHz), respectively. The DC power consumption is about 417 mW, resulting in a power-added-efficiency of 0.92\\%. This power amplifier has the highest absolute small-signal bandwidth and highest output power in the J-Band for a silicon power amplifier without additional power combining. Without the balun at the input and output, the amplifier provides upto 8.1 dBm and a small-signal gain above 20 dB in an integrated differential circuit.

A 239-298 GHz Power Amplifier in an Advanced 130 nm SiGe BiCMOS Technology for Communications Applications

**Please read the paper on the following link:**

https://1worldcontent.com/ess/9219.pdf

**Abstract:**

This paper introduces a phase shifter based on switched filters for mm-wave 5G MIMO transmitters. It is realized in 22nm FD-SOI CMOS and exploits the use of back-gate biasing. The new approach features strong tolerance to process, voltage and temperature (PVT) variations and thus can maintain low phase error with fine phase tuning capability supporting a large bandwidth. Measurement results show that the 4-bit phase shifter achieves 3.5 degree rms phase error at 28 GHz. The proposed phase shifter can maintain <5 degree of the worst-case rms phase error when operating across 24 to 29.5 GHz resulting in 20.56% fractional bandwidth which is the largest among the published switched-filter phase shifters to date.

A 28-GHz Switched-Filter Phase Shifter with Fine Phase-Tuning Capability Using Back-Gate Biasing in 22-nm FD-SOI CMOS

**Please read the paper on the following link:**

https://ieeexplore.ieee.org/document/9199382

**Abstract:**

The Von-Neumann bottleneck is a clear limitation for data-intensive applications, bringing in-memory computing (IMC) solutions to the fore. Since large data sets are usually stored in nonvolatile memory (NVM), various solutions have been proposed based on emerging memories, such as OxRAM, that rely mainly on area hungry, one transistor (1T) one OxRAM (1R) bit-cell. To tackle this area issue, while keeping the programming control provided by 1T1R bit-cell, we propose to combine gate-allaround stacked junctionless nanowires (1JL) and OxRAM (1R) technology to create a 3-D memory pillar with ultrahigh density. Nanowire junctionless transistors have been fabricated, characterized, and simulated to define current conditions for the whole pillar. Finally, based on Simulation Program with Integrated Circuit Emphasis (SPICE) simulations, we demonstrated successfully scouting logic operations up to three-pillar layers, with one operand per layer.

Ultrahigh-Density 3-D Vertical RRAM with Stacked Junctionless Nanowires for In-Memory-Computing Applications

**Please read the paper on the following link:**

https://ieeexplore.ieee.org/document/9212585

**Abstract:**

We propose, for the first time, an indium gallium zinc oxide (IGZO)-based 2T1C compute cell (IGZO-cell) for analog in-memory computing. To assess the impact of an IGZO-cell-based array including the periphery on power and accuracy, a PyTorch framework was developed to analytically modeled analog components. The results are reported for a ResNet20 network on the Canadian Institute For Advanced Research-10 (CIFAR-10) benchmark. The state-of-the-art energy efficiency of 15 peta operations per second (POPS)/W including the periphery is achieved by using our proposed IGZO-cell with CMOS compatibility. Finally, it is shown that, with a properly trained neural network model, there is no degradation of test accuracy with 10% device to device variability for the IGZO devices.

IGZO-Based Compute Cell for Analog In- Memory Computing—DTCO Analysis to Enable Ultralow-Power Ai at Edge

**Please read the paper on the following link:**

https://ieeexplore.ieee.org/document/9144248

**Abstract:**

This letter proposes a C-SRAM combining IMC/NMC approaches to be used by a scalar processor as an energyefficient vector processing unit. The proposed circuit is designed with a two-port foundry bitcell and an adjustable form factor to facilitate physical implementation in a SoC. The 4-kB C-SRAM testchip of 128-b words manufactured in 22-nm FD-SOI technology displays a subarray efficiency of 72% as well as an additional computing area of less than 5%. The measurements at 0.85 V and 1 GHz demonstrate an energy efficiency per unit area of 35.6 and 1.48 TOPS/W/mm2 for 8-b additions and multiplications with 3- and 24-ns computing latency, respectively.
