In this paper, a broad-purpose compute-inmemory solution (±CIM) able to handle arbitrary sign in both inputs/features and weights/coefficients is introduced. The ability to operate on arbitrary sign and under variable precision on both operands enables a wide range of applications, ranging from conventional neural networks to digital signal processing and monitoring. The ±CIM pipelined architecture, the reconfigurable row encoder and the adoption of a commercial 2-port bitcell allow uninterrupted memory availability for conventional read/write, even when performing in-memory computations.

ESSCIRC ESSDERC 2021

Broad-Purpose In-Memory Computing for Signal Monitoring and Machine Learning Workloads

speech detection

broad-purpose processing

compute-in-memory

signal processing

convolutional neural networks
